Euro2.3.4.5 standard honeycomb ceramic substrate

Honeycomb ceramic is used as DOC, SCR and DPF substrate. It features higher cpsi, thin wall and higher specific surface area, etc. After being coated with precious metal, it is applied to diesel and gasoline exhaust system and industrial gas treatment. We make customized production based on your specification


Product Detail

Product Tags

More details of products

* Environmental-friendly

* Wear-resistant, long lifespan

* Main raw material: cordierite ceramic and is the key component of three-way catalytic converter.

* High temperature resistance;

* High mechanical strength;

What information do you need from me if l have a request?

We promise would be a good consultant if you are not certain about your detailed requests. So just feel free to contact us when you see our this page. But it would be perfect if you could provide full information while you sending us the inquiry. That would be very helpful to shorten our communication. Usually we need below information to quote the corresponding  price:1) Which model of product do you want?

2) Material

3) Dimension (For customized models products, a draft paper would be perfect

4) Coating demands (For products that need noble metal coating)

5)Applications

6) Quantity

Parameters

Product name Ceramitic Honeycomb Substrate
Model Number DJN0501
Brand Name DJN
Emission Standard: EURO 2/3/4/5
Market Type OEM or Aftermarket
Overall dimension (mm) 120*80*50mm
Material  cordierite
The hole density: 100-900 CPSI.
Applications Vehicle, RTO, HTAC, RCO, VOC and SCR
Wall Thickness: 0.430.60.670.731.11.01.41.41.5 mm
Warranty 30000 miles performance/2 years
Color White/Brown
Shape Round, Oval, Racetrack, or Customized
Certification ISO 9001
MOQ: 50 pcs
Supply Ability 1000 Piece/Pieces per Week
Place of Origin: Jiangsu
SAMPLE ORDER: Accept
Condition new
Function reduce harmful emission (CO,HC,NO) from motor vehicle Over 95% conversion efficiency;
Supply Ability 1000 Piece/Pieces per Month
Packaging & delivery Air bubble film and Carton Packing, inside fix the product decently with expanded material
Port Shanghai/Ningbo
Lead time: 10-30 days .
Active catalyst ingredients Pt, Pd, Rh, and rare earth elements

Video

https://youtube.com/shorts/JszgRiETKxA
