Ceramic Honeycomb Manufacturing Catalytic Auto Universal Catalytic Converter

Efficiency

Lower burning temperature:
CO: ≤241°C
HC: ≤246°C
NO2: ≤264°C
Higher conversion efficiency:
CO: ≥96%
HC: ≥95%
NO2: ≥90%


Product Detail

Product Tags

Characteristics of the Honeycomb:

1. Large specific surface area: to ensure full access to the exhaust gas with the catalyst;

2. Stable water absorption: to ensure the catalyst evenly firmly attached to the surface of the honeycomb substrate.

3. Warm-up: after start-up the engine, the temperature of the carrier can reach the catalyst activation temperature in the shortest possible time.

4. Low exhaust resistance: the engine’s exhaust resistance is small, to ensure that doesn’t affect the engine performance.

5. High strength: the operating environment of the honeycomb substrate is in the bumpy car, so the honeycomb substrate must be high strength without being external damage.

6. Good assembly: the carrier is an exhaust assembly parts, only good appearance and precise dimensions can ensure perfect assembly.

Parameters

Product name Universal three way  catalytic converter
Model Number DJN0405
Brand Name DJN
Emission Standard: EURO 2/3/4/5
OE NO.
Year:
Car Fitment: Universal three way  catalytic converter
Overall length (mm) 200mm
Inlet/outlet Diameter (mm) 4''/105mm
Material Inside : ceramic(honeycomb) substrate 400cpsi with mat
Shell :304 or 409 # stainless steel shell,stainless steel pipe
Oxygen sensor ports NO
cpsi 400 /600/800
Wall thickness 0.09±0.025
Warranty 30000 miles performance/2 years
Packaging: Air bubble film and Carton Packing
MOQ: 50 pcs
Supply Ability 1000 Piece/Pieces per Week
Place of Origin: Jiangsu
SAMPLE ORDER: Accept
Condition new
Function reduce harmful emission (CO,HC,NO) from motor vehicle Over 95% conversion efficiency;
Service Customers' specific demands available, design drawings are welcomed. OEM service is accepted
Supply Ability 1000 Piece/Pieces per Month
Packaging & delivery Air bubble film and Carton Packing, inside fix the product decently with expanded material
Port Shanghai/Ningbo
Lead time: 10-30 days .
Active catalyst ingredients Pt, Pd, Rh, and rare earth elements
Shape round, oval, race track
